Forgot Password? The section for each edition contains links to supplemental files and software, non-ARRL documents, and errata and corrections. This is not a problem on Vista or Windows 7. The following problem description identifies the issue:. Symptoms may include: The disc is not recognized at all. Running the Microsoft Fix It application associated with this problem should take care of the problem. Windows 7 limits on the length of filename paths is also sometimes exceeded.
A possible workaround is as follows:. Create a directory file folder called Data Files. Within this folder create the file folder Yagi. Into this folder copy the entire contents of the YW Yagi for Windows folder from the hard disk. The program should now work without need for the CD disk.
Windows 7 users also report problems opening files associated with some of the Antenna Book software, such as YW Yagis for Windows. Examine it with a word processor.
Additional information is available at www. The good news is, most of the software runs just fine, once you get past the security issues. Due to issues with hackers writing malicious arrl antenna book 23rd edition pdf free download, Microsoft has implemented tougher measures to prevent hackers from gaining control of your computer.
In order for programs like Yagi for Windows to write and modify files, so you can save your work, you need to explicitly grant the programs Administrative Privileges, by clicking the appropriate box in the security window for the program. You need to change the settings for the program. You may also download these software notes from the 21st edition with additional information about the Antenna Book's companion software.
The installer program creates several icons on the desktop during the install process. These icons all have similar names and it can be difficult to determine the correct shortcut. The names of the shortcuts can be edited by right-clicking the icon and selecting "Rename".
The name can then be changed to something more descriptive in a few characters that are displayed with the shortcut. Readme - this is the installation and operation instruction document that comes with the Antenna Book software. This package has been updated from the version supplied with the 21st edition. The ZIP file contains a help file Arrayfeed1. ZIP that corrects a calculation problem that fails to find solutions to the calculations when the combination of the desired feed line impedance exceeds the product of the raw antenna resistance and the gamma step-up value.
See the Errata and Corrections section below for notes about the dimensions for torque compensators and three corrected YW files for the modified Hygain antennas. Dimensions for the monoband Yagi hairpin matching inductors are given in the YW file for that antenna. Scroll to the end of the file to see the hairpin dimensions. EXE - the software - plus a desktop icon file. The compressed file includes AAT.
The new data site is called arrl antenna book 23rd edition pdf free download "National Map". This updated version 1. However, the "Save radials" option, although present, may be greyed out and cannot be selected. Thanks, Doc N7DR. That should enable the "save radials" option during the viewshed procedure. During the original CD installation process you were asked to specify the region where you live so that appropriate statistical elevation-angle files could be installed along with HFTA.
You may wish to replace the files currently in this directory with these to achieve greater accuracy. The statistical elevation angles are computed for the full year solar cycle from transmitting sites indicated by the filename. Graphing Spreadsheets by Rudy Severns, N6LF - In the process of generating the graphs for several figures in Chapter 3, typical values were chosen for such variables as vertical height, frequency of operation, power level, ground characteristics, etc.
In these spreadsheets, you can choose your own values for those variables and the graphs will change accordingly. The compressed ZIP file includes two spreadsheets and an instruction document. Seawater Grounds by Rudy Severns, N6LF - In this article, Rudy addresses the situation of installing a vertical antenna on a dock, pier, or beach and the effectiveness of using salt water as a ground. Dimensions for the monoband Yagi hairpin matching wires are given in the YW file for that antenna.
Be sure to download the element detail drawingarrl antenna book 23rd edition pdf free download well. Figure Giving a single equation for parallel-conductor lines with plastic insulation is not practical because of the many variations in dielectric cross-section. For these cases, check with the feed line manufacturer for the correct characteristic impedance.
The paper provides general information about communications effectiveness as related to the physical height of antennas. The intended audience is amateur radio operators and the city and town Planning Boards before which a radio amateur must sometimes appear to obtain building permits for radio towers and antennas.
Rotator Specifications - This PDF document lists a number of popular rotators along with their specifications for rotating and braking torque. The list is not meant to be exhaustive or complete - it was last edited in July Updates may be sent to antennabook arrl. Manufacturers and Material Suppliers Spreadsheet - This spreadsheet Excel format - XLS contains directories for service providers, and for suppliers and manufacturers of materials and components for antenna system construction and maintenance, arrl antenna book 23rd edition pdf free download.
Distributors are not listed - see QST magazine. The spreadsheet also calculates the distance arrl antenna book 23rd edition pdf free download the point of measurement to the top of the tree or pole. The author conducted a study of quarter-wavelength vertical antennas used on bands higher in frequency than that for which they were designed. The article describes a low-visibility multiband loop using an auto-tuner to operate from an antenna-restricted apartment. In the table of schematic symbols, the vacuum tube symbol labeled "Twin Triode" is actually that of a "Twin Tetrode".
Section 1. Gain with respect to an isotropic antenna is stated as dBi. Gain with respect to this value is denoted dBd. To convert from gain given as dBi to dBd, subtract 2. Note that to specify gain in dBd, the dipole must be at the same effective height as the antenna being specified.
Alternately, the free-space values for gain could be used. Be sure to state clearly which set of values are used. These calculated gains and elevation angles are examples meant to illustrate the large effect that height above ground can have on antenna pattern. They are unlikely to be exactly correct for a real antenna in an actual installation. Figure arrl antenna book 23rd edition pdf free download not printed correctly.
The URL for the reference R. The complete paper is available as a PDF version here. Thanks, Dean N6BV. Figure 5. Pagetop of right-hand column: the reference to " dashed slanted lines " on Figure 7. B should simply be to " slanted lines " as only the line corresponding to an alpha value of 2 is dashed. In general, dBd is a reference to the gain of a dipole located exactly at the same effective height as the comparison antenna and oriented so that its maximum gain is in the same direction as that of the comparison antenna.
Thanks, Tom W8JI. Note that for the optimized single-band designs sections For the optimized Hygain designs section Table Director 3 for the CA is missing. It has a spacing of " and the element tip is 55". Note that because the HyGain boom-to-element clamps require several inches of boom, the elements can't be mounted exactly at the end of the boom.
Since the boom length of 34' is the same as the sum of element spacings, Director 3 can not have a spacing of " and will have to be a few inches less. This does not result in a significant change in antenna pattern according to designer N6BV. The YW files for some of the modified Hygain antennas are missing some information due to lines in the file having been dropped. Here are the correct versions of the file.
No other files need to be replaced. When using "Save As" to store a modified YW file the program sometimes leaves out a line of the notes, arrl antenna book 23rd edition pdf free download. Check the updated file by using a text editor such as Notepad to be sure all the information is saved correctly or to make corrections. Section Thanks, Tom NC6B.
In Tables and for the and element MHz Yagis, arrl antenna book 23rd edition pdf free download, the second column data is position from the end of the boom, not from the reflector, arrl antenna book 23rd edition pdf free download.
Part 1 and Part 2. In section The dimensions in the table are for Amphenol connectors only. Equation All four equations should have minus signs between the coefficient a1, a2, b1, b2 and the fraction. This version click here to download the file corrects those problems.
